2SD965 d965 的参数 |
| 集电极-基极反向击穿电压V(BR)CBO
Collector-Base Voltage(VCBO) |
40V |
| 集电极-发射极反向击穿电压V(BR)CEO
Collector-Emitter Voltage(VCEO) |
20V |
| 集电极连续输出电流IC
Collector Current(IC) |
5A |
| 截止频率fT
Transtion Frequency(fT) |
150MHz |
| 直流电流增益hFE
DC Current Gain(hFE) |
230~600 |
| 管压降VCE（sat）
Collector-Emitter Saturation Voltage |
1V |
| 耗散功率Pc
Power Dissipation |
750mW/0.75W |
| Description & Applications |
Silicon NPN epitaxial planer type For low-frequency power amplification For stroboscope Features Low collector to emitter saturation voltage VCE(sat) Satisfactory operation performances at high efficiency with the low-voltage power supply |
| 描述与应用 |
NPN硅外延平面型 对于低频功率放大频闪 特点 低集电极到发射极饱和电压VCE（SAT） 高效率，令人满意的操作性能 低电压供电 |
