AHC1G86DCKR AHY 的参数 |
| 逻辑类型
Logic Type |
异或门 XOR Gate |
| 电路数
Number of Circuits |
1 |
| 输入数
Number of Inputs |
2 |
| 电源电压Vcc
Voltage - Supply |
2V~5.5V |
| 静态电流Iq
Current - Quiescent (Max) |
1uA |
| 输出高，低电平电流
Current - Output High, Low |
-8mA，8mA |
| 低逻辑电平
Logic Level - Low |
0.5V~1.65V |
| 高逻辑电平
Logic Level - High |
1.5V~3.85V |
| 传播延迟时间@Vcc，CL
Max Propagation Delay @ V, Max CL |
8.8ns @ 5V，50pF |
| Description & Applications |
single 2-input exclusive-or gate;Features Operating Range of 2 V to 5.5 V Max tpd of 8 ns at 5 V Low Power Consumption, 10-μA Max ICC ±8-mA Output Drive at 5 V Schmitt Trigger Action at All Inputs Makes the Circuit Tolerant for Slower Input Rise and Fall Time |
| 描述与应用 |
单双输入异或门;特性 2 V至5.5 V的工作范围 最大为8 ns在5 V吨 低功耗，10μA最大ICC ±8 mA输出驱动在5 V 施密特触发器动作在所有输入使 电路容错输入较慢的上升和下降时间 |
